MSP-EXP430G2 -

Integrated USB-powered Flash Emulation Tool, MSP430G2XX, Launchpad, 14/20 Pin DIP Socket, LED's

Image is for illustrative purposes only. Please refer to product description.

Manufacturer Part No:
MSP-EXP430G2
Order Code:
1853793
Technical Datasheet:
(EN)
See all Technical Docs

Product Information

:
LaunchPad Emulator, Mini USB-B Cable, Quick Start Guide
:
MSP430
:
16bit
:
MSP430
:
MSP430G2xx
:
-
:
MSP430
:
Texas Instruments
Find similar products Choose and modify the attributes above to find similar products.

Product Overview

MSP-EXP430G2 Launch Pad is easy-to-use Flash programmer and debugging tool for the MSP430G2xx Value Line microcontrollers. It features everything users need to start developing on an MSP430 microcontroller device. It has on-board emulation for programming and debugging and features a 14/20 pin DIP socket, on-board buttons and LEDs & Booster Pack-compatible pinouts that support a wide range of plug-in modules for added functionality.
  • Enables development on any MSP430 Value Line device with 14- or 20 pin DIP (N) packages
  • LaunchPad's integrated emulator interface connects Flash based MSP430 Value Line devices to a PC
  • Includes one mini USB cable to interface with a PC.
  • Included MSP430G2xx devices feature preloaded sample programs.
  • Free downloadable versions of IAR Kick-start and Code Composer Studio Version 5
  • 2 programmable LEDs, 1 power LED, 1 programmable button, 1 reset button
  • Built-in Flash emulation for debugging and programming
  • 10pin PCB connector
  • RoHS compliant

Applications

Power Management, Sensing & Instrumentation, Embedded Design & Development

Contents

MSP430G2553IN20 Flash device (preloaded with sample program10 pin PCB Connector (2 male/2 female) 32KHz crystal, Launch Pad Development board (MSP-EXP430G2), Launch Pad sticker, Mini USB cable, Quick Start Guide
