PCB Receptacle, Wire-to-Board, 1.27 mm, 2 Rows, 24 Contacts, Surface Mount, TMM Series


Image is for illustrative purposes only. Please refer to product description.

Manufacturer Part No:
Order Code:
Product Range
TMM Series
Technical Datasheet:
TMM-6-L-24-1   Datasheet
See all Technical Docs

Product Range Selector (TMM Series)

See all from this product range

Product Overview

The TMM series staggered MicroMatch Connector designed for board-to-board and wire-to-board interconnections offering a large number of positions. The MicroMatch connectors are available in even number of positions from 4 to 26, with fully tinned contacts. The polarization guide on male connectors is to ensure the right orientation. Kinked contacts on connectors are intended to provide significant connector retention on PCB while soldering operations. Locking latches are available on female connectors.
  • 20mR Maximum contact resistance
  • 1000MR Minimum insulation resistance


Aerospace, Defence, Military

Product Information

Want to see similar products? Simply select your required attributes below and hit the button ×





Surface Mount

TMM Series


Tin Plated Contacts
