PAXLR000
Digital Panel Meter, Tachometer, PAX Lite, 6 Digits, Frequency, 0.01Hz to 25kHz
Image is for illustrative purposes only. Please refer to product description.
ManufacturerRED LION
Manufacturer Part NoPAXLR000
Order Code1253447
Product RangeTUK SGACK902S Keystone Coupler
Technical Datasheet
No Longer Stocked
Product Information
ManufacturerRED LION
Manufacturer Part NoPAXLR000
Order Code1253447
Product RangeTUK SGACK902S Keystone Coupler
Technical Datasheet
No. of Digits / Alpha6
Meter FunctionFrequency
Meter Range0.01Hz to 25kHz
Digit Height14.2mm
Panel Cutout Height45mm
Panel Cutout Width92mm
Supply Voltage Min10VDC
Supply Voltage Max16VDC
Operating Temperature Min0°C
Operating Temperature Max60°C
Product RangeTUK SGACK902S Keystone Coupler
SVHCNo SVHC (08-Jul-2021)
Product Overview
The PAXLR000 is a PAX® Lite 6-digit Rate Meter provides the versatility and flexibility needed to accommodate virtually any rate measuring application. The meter has the ability to scale for direct readout in terms of the units being measured. They can accommodate magnetic pickups, logic sensors and NPN open collector sensors. The pulses are received and scaled, so the desired display can be achieved. The meter is programmed through both the front panel buttons and DIP switches.
- 6-digit Red LED display
- Programming scaling
- Programmable decimal points
- Programmable update time
- Rate indication
- -0 to 60°C Operating temperature range
Applications
Industrial, Automation & Process Control, Test & Measurement
Technical Specifications
No. of Digits / Alpha
6
Meter Range
0.01Hz to 25kHz
Panel Cutout Height
45mm
Supply Voltage Min
10VDC
Operating Temperature Min
0°C
Product Range
TUK SGACK902S Keystone Coupler
Meter Function
Frequency
Digit Height
14.2mm
Panel Cutout Width
92mm
Supply Voltage Max
16VDC
Operating Temperature Max
60°C
SVHC
No SVHC (08-Jul-2021)
Technical Docs (1)
Legislation and Environmental
Country of Origin:
Country in which last significant manufacturing process was carried outCountry of Origin:United States
Country in which last significant manufacturing process was carried out
Country in which last significant manufacturing process was carried outCountry of Origin:United States
Country in which last significant manufacturing process was carried out
Tariff No:90292038
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:To be advised
SVHC:No SVHC (08-Jul-2021)
Download Product Compliance Certificate
Product Compliance Certificate
Weight (kg):.508023
