MELF SMD Resistors | e絡盟 Hong Kong

We offer Carbon Film, Metal Film, Thin Film, and Thick Film MELF SMD resistors, in resistance values from 0.1Ω to 10MΩ.

What are the advantages of MELF resistors?

MELF SMD resistors are the perfect choice for applications where reliability and stability are of major concern at higher power ratings and higher operating voltages.

Many electronic circuits are exposed to high pulse loads. This means that pulse-proof resistors are essential for protecting the circuit’s electronic components. These must be excellent in both pulse handling and long term stability, with low drift.

MELF SMD resistors offer a good solution. Although they are a thin film type, they are cylindrical rather than flat. This gives them a surface three times larger than a thin film resistor of the same size. This design also allows a helical trimming pattern to be used, enabling a uniform current distribution. Therefore, they can distribute heat more efficiently so their pulse load capability is five times higher, and their long term stability is excellent as well.

Apart from the standard metal film technology, MELF resistors are also available with carbon film, which has unrivalled thermal stability; this further enhances their pulse load capability.

MELF resistor package sizes

element14 offers MELF resistors in package sizes from 0102 (2211 Metric) to 2512 (6432 Metric). We also offer 3614 Metric products.

No Filter(s) Applied

0 Filter(s) Selected

			Price For		Quantity

SMA-Q0207FTDT2R74	4461329 Data Sheet RoHS	TE CONNECTIVITY - NEOHM MELF SMA-Q 2R74 50PPM 0207 1W	Each (Supplied on Cut Tape) Cut Tape	5+ HK$6.000 50+ HK$3.000 250+ HK$1.760 500+ HK$1.600 1000+ HK$1.450 More Pricing...	Total:HK$30.00 Min: 5 / Mult: 5	-	-	-	-	-	-	-	-	-	-	-
SMA-Q0207FTDT2R74	4461329RL Data Sheet RoHS	TE CONNECTIVITY - NEOHM MELF SMA-Q 2R74 50PPM 0207 1W	Each (Supplied on Cut Tape) Re-Reel Packaging Options	50+ HK$3.000 250+ HK$1.760 500+ HK$1.600 1000+ HK$1.450 2000+ HK$1.430	Total:HK$300.00 Min: 100 / Mult: 5	-	-	-	-	-	-	-	-	-	-	-
MMA02040C1002FB300	3087906 Data Sheet RoHS	VISHAY RESISTOR FILM 10K 0.25W 1% 1405	Each (Supplied on Cut Tape) Cut Tape	5+ HK$0.855 50+ HK$0.326 250+ HK$0.308 500+ HK$0.302 1500+ HK$0.296	Total:HK$4.28 Min: 5 / Mult: 5	10kohm	MMA Series	200V	Metal Film	400mW	± 1%	± 50ppm/°C	MiniMELF 0204	-55°C	155°C	AEC-Q200
MMU01020C4702FB300	1215976 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 47 kohm MMU Series 100 V Metal Film 200 mW ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$0.855 50+ HK$0.616 250+ HK$0.539 500+ HK$0.514 1500+ HK$0.480 More Pricing...	Total:HK$4.28 Min: 5 / Mult: 5	47kohm	MMU Series	100V	Metal Film	200mW	± 1%	± 50ppm/°C	MicroMELF 0102	-55°C	125°C	AEC-Q200
WRM0204C-22RFI	1505781 Data Sheet RoHS	TT ELECTRONICS / WELWYN Surface Mount MELF Resistor 22 ohm WRM Series 200 V Metal Film 250 mW ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$2.230 50+ HK$1.260 250+ HK$0.557 500+ HK$0.531 1500+ HK$0.505 More Pricing...	Total:HK$11.15 Min: 5 / Mult: 5	22ohm	WRM Series	200V	Metal Film	250mW	± 1%	± 50ppm/°C	MiniMELF 0204	-55°C	125°C	-
SMM02040D1001BB300	2616696 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor Mini MELF 1 kohm SMM Series 200 V Thin Film 250 mW ± 0.1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$5.310 50+ HK$2.580 250+ HK$2.020 500+ HK$1.840 1500+ HK$1.470 More Pricing...	Total:HK$26.55 Min: 5 / Mult: 5	1kohm	SMM Series	200V	Thin Film	250mW	± 0.1%	± 25ppm/K	MiniMELF 0204	-55°C	155°C	AEC-Q200
MMA02040C6800FB300	3087761 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 680 ohm MMA Series 200 V Metal Film 250 mW ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$0.855 50+ HK$0.395 250+ HK$0.352 500+ HK$0.326 1500+ HK$0.308	Total:HK$4.28 Min: 5 / Mult: 5	680ohm	MMA Series	200V	Metal Film	250mW	± 1%	± 50ppm/°C	MiniMELF 0204	-55°C	125°C	AEC-Q200
MMB02070C1009FB200	3086604 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 10 ohm MMB Series 300 V Metal Film 1 W ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$1.380 50+ HK$0.984 250+ HK$0.865 500+ HK$0.813 1000+ HK$0.762 More Pricing...	Total:HK$6.90 Min: 5 / Mult: 5	10kohm	MMB Series	300V	Metal Film	1W	± 1%	± 50ppm/°C	MELF 0207	-55°C	125°C	AEC-Q200
MMA02040C1000FB300	3087669 Data Sheet RoHS	VISHAY RESISTOR FILM 100R 0.25W 1% 1405	Each (Supplied on Cut Tape) Cut Tape	5+ HK$0.855 50+ HK$0.395 250+ HK$0.352 500+ HK$0.326 1500+ HK$0.283	Total:HK$4.28 Min: 5 / Mult: 5	100ohm	MMA Series	200V	Metal Film	250mW	± 1%	± 50ppm/K	MiniMELF 0204	-55°C	155°C	AEC-Q200
MMB02070C1003FB200	3087086 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 100 kohm MMB Series 300 V Metal Film 1 W ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$1.380 50+ HK$0.984 250+ HK$0.855 500+ HK$0.813 1000+ HK$0.719 More Pricing...	Total:HK$6.90 Min: 5 / Mult: 5	100ohm	MMB Series	300V	Metal Film	1W	± 1%	± 50ppm/°C	MELF 0207	-55°C	125°C	AEC-Q200
SMM02040C4709FB300	2616665 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor Mini MELF 47 ohm SMM Series 200 V Thin Film 250 mW ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$1.380 50+ HK$0.514 250+ HK$0.428 500+ HK$0.407 1500+ HK$0.385 More Pricing...	Total:HK$6.90 Min: 5 / Mult: 5	47kohm	SMM Series	200V	Thin Film	250mW	± 1%	± 50ppm/K	MiniMELF 0204	-55°C	155°C	AEC-Q200
MMA02040E3002BB100	3086290 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 30 kohm MMA Series 200 V Metal Film 250 mW ± 0.1%	Each (Supplied on Cut Tape) Cut Tape	1+ HK$10.610 50+ HK$5.340 100+ HK$4.810 250+ HK$4.240 500+ HK$3.860 More Pricing...	Total:HK$10.61 Min: 1 / Mult: 1	30kohm	MMA Series	200V	Metal Film	250mW	± 0.1%	± 15ppm/°C	MiniMELF 0204	-55°C	85°C	AEC-Q200
MMU01020C1001FB300	1215932 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 1 kohm MMU Series 100 V Metal Film 200 mW ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$0.855 50+ HK$0.616 250+ HK$0.539 500+ HK$0.514 1500+ HK$0.446	Total:HK$4.28 Min: 5 / Mult: 5	1kohm	MMU Series	100V	Metal Film	200mW	± 1%	± 50ppm/°C	MicroMELF 0102	-55°C	125°C	AEC-Q200
MMA02040E4702BB100	3086343 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 47 kohm MMA Series 200 V Metal Film 250 mW ± 0.1%	Each (Supplied on Cut Tape) Cut Tape	1+ HK$10.610 50+ HK$5.340 100+ HK$4.810 250+ HK$4.240 500+ HK$3.860 More Pricing...	Total:HK$10.61 Min: 1 / Mult: 1	47kohm	MMA Series	200V	Metal Film	250mW	± 0.1%	± 15ppm/°C	MiniMELF 0204	-55°C	85°C	AEC-Q200
MMA02040E2701BB100	3086045 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 2.7 kohm MMA Series 200 V Metal Film 250 mW ± 0.1%	Each (Supplied on Cut Tape) Cut Tape	1+ HK$7.880 50+ HK$5.070 100+ HK$4.570 250+ HK$4.040 500+ HK$3.690 More Pricing...	Total:HK$7.88 Min: 1 / Mult: 1	2.7kohm	MMA Series	200V	Metal Film	250mW	± 0.1%	± 15ppm/°C	MiniMELF 0204	-55°C	85°C	AEC-Q200
MMB02070C1002FB200	3086963 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 10 kohm MMB Series 300 V Metal Film 1 W ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$1.380 50+ HK$0.984 250+ HK$0.865 500+ HK$0.813 1000+ HK$0.736 More Pricing...	Total:HK$6.90 Min: 5 / Mult: 5	10kohm	MMB Series	300V	Metal Film	1W	± 1%	± 50ppm/°C	MELF 0207	-55°C	125°C	AEC-Q200
MMU01020C1002FB300	1215959 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 10 kohm MMU Series 100 V Metal Film 200 mW ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$0.813 50+ HK$0.513 250+ HK$0.449 500+ HK$0.432 1500+ HK$0.424	Total:HK$4.06 Min: 5 / Mult: 5	10kohm	MMU Series	100V	Metal Film	200mW	± 1%	± 50ppm/°C	MicroMELF 0102	-55°C	125°C	AEC-Q200
MMA02040C1000FB300	3087669RL Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 100 ohm MMA Series 200 V Metal Film 250 mW ± 1%	Each (Supplied on Cut Tape) Re-Reel Packaging Options	500+ HK$0.326 1500+ HK$0.283	Total:HK$163.00 Min: 500 / Mult: 5	100ohm	MMA Series	200V	Metal Film	250mW	± 1%	± 50ppm/K	MiniMELF 0204	-55°C	155°C	AEC-Q200
SMM02040C1004FB300	2616602 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor Mini MELF 1 Mohm SMM Series 200 V Thin Film 250 mW ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$0.942 50+ HK$0.369 250+ HK$0.360 500+ HK$0.330 1500+ HK$0.300 More Pricing...	Total:HK$4.71 Min: 5 / Mult: 5	1kohm	SMM Series	200V	Thin Film	250mW	± 1%	± 50ppm/K	MiniMELF 0204	-55°C	155°C	AEC-Q200
CMB02070X5100GB200	3547326 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 510 ohm CMB Series 500 V Carbon Film 1 W ± 2%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$4.460 50+ HK$3.140 250+ HK$2.510 500+ HK$2.100 1000+ HK$1.780 More Pricing...	Total:HK$22.30 Min: 5 / Mult: 5	510ohm	CMB Series	500V	Carbon Film	1W	± 2%	-	MELF 0207	-55°C	155°C	AEC-Q200
MMA02040C1502FB300	3087920 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 15 kohm MMA Series 200 V Metal Film 250 mW ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$0.855 50+ HK$0.395 250+ HK$0.352 500+ HK$0.326 1500+ HK$0.283 More Pricing...	Total:HK$4.28 Min: 5 / Mult: 5	15kohm	MMA Series	200V	Metal Film	250mW	± 1%	± 50ppm/°C	MiniMELF 0204	-55°C	125°C	AEC-Q200
MMA02040C1504FB300	3088169 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 1.5 Mohm MMA Series 200 V Metal Film 250 mW ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$1.380 50+ HK$0.565 250+ HK$0.428 500+ HK$0.424 1500+ HK$0.420 More Pricing...	Total:HK$6.90 Min: 5 / Mult: 5	1.5Mohm	MMA Series	200V	Metal Film	250mW	± 1%	± 50ppm/°C	MiniMELF 0204	-55°C	125°C	AEC-Q200
MMB02070C1501FB200	3086860 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 1.5 kohm MMB Series 300 V Metal Film 1 W ± 1%	Each (Supplied on Cut Tape) Cut Tape	10+ HK$0.943 100+ HK$0.807 500+ HK$0.662 1000+ HK$0.596 2000+ HK$0.583 More Pricing...	Total:HK$9.43 Min: 10 / Mult: 10	1.5Mohm	MMB Series	300V	Metal Film	1W	± 1%	± 50ppm/°C	MELF 0207	-55°C	125°C	AEC-Q200
CMB02070X2202GB200	1713634 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 22 kohm CMB Series 500 V Carbon Film 400 mW ± 2%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$6.850 50+ HK$3.330 250+ HK$2.700 500+ HK$2.440 1000+ HK$2.130 More Pricing...	Total:HK$34.25 Min: 5 / Mult: 5	22ohm	CMB Series	500V	Carbon Film	400mW	± 2%	-	MELF 0207	-55°C	155°C	AEC-Q200
MMA02040C3309FB300	3087608 Data Sheet RoHS	VISHAY Surface Mount MELF Resistor 33 ohm MMA Series 200 V Metal Film 250 mW ± 1%	Each (Supplied on Cut Tape) Cut Tape	5+ HK$0.855 50+ HK$0.395 250+ HK$0.352 500+ HK$0.326 1500+ HK$0.275 More Pricing...	Total:HK$4.28 Min: 5 / Mult: 5	33ohm	MMA Series	200V	Metal Film	250mW	± 1%	± 50ppm/°C	MiniMELF 0204	-55°C	125°C	AEC-Q200
