Speed sensor is a type of sensor which measures the speed of a moving object.

Types of speed sensors:

Magnetic speed sensors: Sensors which use magnetic field to detect the rotational speed of a wheel or shaft
Optical speed sensors: Sensors which use an optical beam to detect the movement of an object
Hall effect speed sensors: Sensors which use hall effect to the measure the rotational speed of a wheel or shaft
Capacitive speed sensors: Sensors which use change in capacitance to measure the rotational speed of a wheel or shaft
Inductive speed sensors: Sensors which use change in inductance to measure the rotational speed of a wheel or shaft

No Filter(s) Applied

0 Filter(s) Selected

			Price For		Quantity

GS100502	1971737 Data Sheet RoHS	ZF Hall Effect Sensor Speed Geartooth 15 kHz Sink Output 400 mV out Cylindrical 5 to 24 VDC	Each	1+ HK$272.590 5+ HK$250.120 10+ HK$241.820 25+ HK$231.670 50+ HK$230.580 More Pricing...	Min: 1 / Mult: 1	-	5VDC	5V	24VDC	24V	Wire Leads	Cylindrical	-40°C	Sink	125°C	-	Hall Effect Gear Tooth	-	400mV	-	-	-	-	-	-	-	GS1005 Series
GS100701	4608951 Data Sheet RoHS	ZF HALL EFFECT GEAR TOOTH SENSOR 5 TO 24V	Each	1+ HK$265.540 5+ HK$242.970 10+ HK$229.290 50+ HK$223.040 100+ HK$217.320	Min: 1 / Mult: 1	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
SNG-QPLA-000.	2497574 Data Sheet RoHS	HONEYWELL SPEED & DIRECTION SENSOR 4 WIRE CABLE	Each	1+ HK$528.630 5+ HK$487.750 10+ HK$472.630	Min: 1 / Mult: 1	-	4.5VDC	-	26VDC	-	-	-	-40°C	-	-	-	-	-	-	-	-	-	-	-	35mm	-	-
GS100102	2691338 Data Sheet RoHS	ZF SPEED SENSOR HALL-EFFECT 5-24VDC	Each	1+ HK$447.930	Min: 1 / Mult: 1	-	5VDC	-	24VDC	-	Cable	-	-40°C	-	-	-	-	-	-	400V p-p	-	-	-	-	-	-	-
GS101201	2292987 Data Sheet RoHS	ZF Speed Sensor Geartooth GS1012 Series 5 to 24 Vdc 6 mA 5 μs Connector	Each	1+ HK$246.960 5+ HK$226.370	Min: 1 / Mult: 1	Sink	5VDC	5V	24VDC	24V	Connector	-	-40°C	-	125°C	20mA	Hall Effect Gear Tooth	400mV	-	-	-	-	-	-	-	-	-
SNDH-T4L-G01	1566216 Data Sheet RoHS	HONEYWELL Hall Effect Sensor Speed and Direction SNDH Series Square Wave Output 500 mV out 4.5 to 18 Vdc	Each	1+ HK$1,680.220 5+ HK$1,470.190 10+ HK$1,218.160 25+ HK$1,092.140 50+ HK$1,008.130 More Pricing...	Min: 1 / Mult: 1	-	4.5VDC	-	18VDC	-	Wire Leads	-	-40°C	-	150°C	-	-	-	-	-	-	-	-	-	15mm	-	SNDH Series
GS101205	1704782 Data Sheet RoHS	ZF GEARTOOTH SPEED SENSOR 5 TO 30VDC	Each	1+ HK$327.000 5+ HK$275.790 10+ HK$253.310 50+ HK$245.870 100+ HK$239.120	Min: 1 / Mult: 1	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3030AN	1082215 Data Sheet RoHS	HONEYWELL Speed Sensor VRS 3030 Series Module 1.06 190 Vp-p	Each	1+ HK$3,028.470 5+ HK$2,649.910 10+ HK$2,195.640 25+ HK$1,968.510 50+ HK$1,817.080 More Pricing...	Min: 1 / Mult: 1	-	-	-	-	-	Connector	-	-55°C	-	120°C	-	VRS General Purpose	-	-	190V p-p	450mH	24DP (Module 1.06) or Coarser	910ohm	1.2kohm	19.05mm	0.25m/s	High Output Series
LCZ260-30	2526143 Data Sheet RoHS	HONEYWELL SPEED SENSOR HALL-EFFECT 4.5-26VDC	Each	1+ HK$2,186.620	Min: 1 / Mult: 1	-	4.5VDC	-	26VDC	-	-	-	-40°C	-	125°C	-	-	-	-	-	-	-	-	-	-	-	-
SSH-G01-002-CP-R	4125558 Data Sheet RoHS	AMPHENOL PIHER SENSORS AND CONTROLS Hall Effect Gear Tooth Speed Sensor 13.9 mm CW Reverse 4 to 24 VDC -40 to 125 °C SSH-G01 Series	Each	1+ HK$417.960 5+ HK$385.270	Min: 1 / Mult: 1	-	4VDC	-	24VDC	-	Wire Leads	-	-40°C	-	125°C	-	-	-	-	-	-	-	-	-	13.9mm	-	SSH-G01 Series
SSH-G01-002-CP	4125557 Data Sheet RoHS	AMPHENOL PIHER SENSORS AND CONTROLS Hall Effect Gear Tooth Speed Sensor 13.9 mm CCW 4 to 24 VDC -40 to 125 °C SSH-G01 Series	Each	1+ HK$554.150 10+ HK$434.290	Min: 1 / Mult: 1	-	4VDC	-	24VDC	-	Wire Leads	-	-40°C	-	125°C	-	-	-	-	-	-	-	-	-	13.9mm	-	SSH-G01 Series
SNDH-H3L-G01	3439051 Data Sheet	HONEYWELL Sensor Speed Hall-Effect 4 to 24 VDC Cable -40 °C to 100 °C 9.53 mm SNDH-H Series	Each	1+ HK$1,743.860 5+ HK$1,525.880 10+ HK$1,264.300 25+ HK$1,133.510 50+ HK$1,046.320 More Pricing...	Min: 1 / Mult: 1	-	4VDC	-	24VDC	-	Cable	-	-40°C	-	100°C	-	-	-	-	-	-	-	-	-	9.53mm	-	-
HHT20-ROS	3871412 Data Sheet RoHS	OMEGA Remote Optical Sensor 2.4 m 1.5 VDC 5 to 40 Deg C	Each	1+ HK$2,689.480	Min: 1 / Mult: 1	-	-	-	1.5VDC	-	Cable	-	5°C	-	40°C	-	-	-	-	-	-	-	-	-	-	-	-
LCZ260	3439042 Data Sheet RoHS	HONEYWELL Sensor Speed 4.5 VDC to 26 VDC Wire Leads -40 °C to 125 °C 9.5 mm LCZ Series	Each	1+ HK$2,972.150 5+ HK$2,600.630 10+ HK$2,154.810 25+ HK$1,931.900 50+ HK$1,783.290 More Pricing...	Min: 1 / Mult: 1	-	4.5VDC	-	26VDC	-	-	-	-40°C	-	125°C	-	-	-	-	-	-	-	-	-	9.5mm	-	-
SSH-G01-002-AB	4125556 Data Sheet RoHS	AMPHENOL PIHER SENSORS AND CONTROLS Hall Effect Gear Tooth Speed Sensor 13.9 mm A/B Signal 4 to 24 VDC -40 to 125 °C SSH-G01 Series	Each	1+ HK$418.970 5+ HK$393.750	Min: 1 / Mult: 1	-	4VDC	-	24VDC	-	Wire Leads	-	-40°C	-	125°C	-	-	-	-	-	-	-	-	-	13.9mm	-	SSH-G01 Series
LCZ460	4659342 Data Sheet RoHS	HONEYWELL Hall Effect Zero Speed Sensor Wire Leads 9.5mm Dia Housing LCZ Series	Each	1+ HK$1,775.420 5+ HK$1,774.000 10+ HK$1,772.580 25+ HK$1,771.800	Min: 1 / Mult: 1	-	4.5VDC	-	26VDC	-	Wire Leads	-	-40°C	-	125°C	-	-	-	-	-	-	-	-	-	9.5mm	-	LCZ Series
SNG-QPLA-000	4220247 Data Sheet RoHS	HONEYWELL Speed and Direction Sensor Quadrature Right Angle Exit 4 Wire 500mm Cable SNG-Q Series	Each	1+ HK$528.630 5+ HK$526.110 10+ HK$523.580 25+ HK$521.060 50+ HK$518.530 More Pricing...	Min: 1 / Mult: 1	-	4.5VDC	-	26VDC	-	Cable	-	-40°C	-	150°C	-	-	-	-	-	-	-	-	-	35mm	-	-
.ZH10	2134778 Data Sheet RoHS	HONEYWELL HALL EFFECT ZERO SPEED SENSOR 4 TO 24V	Each	1+ HK$1,974.950 5+ HK$1,666.000 10+ HK$1,454.930 25+ HK$1,395.680	Min: 1 / Mult: 1	-	4VDC	-	24VDC	-	-	-	-40°C	-	100°C	-	Hall Effect Zero Speed Sensor	-	-	-	-	-	-	-	11.9mm	-	-
GS100101	1383380 Data Sheet RoHS	ZF HALL EFFECT GEAR TOOTH SENSOR 5 TO 24V	Each	1+ HK$513.860 5+ HK$462.500 10+ HK$436.510 25+ HK$409.150	Min: 1 / Mult: 1	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
MA3055S10	1541025 Data Sheet RoHS	HONEYWELL Speed Sensor VRS 5.2 Vp-p Module 0.7 Stainless Steel	Each	1+ HK$7,344.390 5+ HK$6,426.340 10+ HK$5,438.400	Min: 1 / Mult: 1	-	-	-	-	-	Wire Leads	-	-73°C	-	230°C	-	VRS General Purpose	-	-	5.5V p-p	85mH	36 DP (Module 0.70) or Coarser	20ohm	45ohm	6.4mm	0.89m/s	High Temperature Series
55075-00-02-A	1608129 Data Sheet RoHS	LITTELFUSE Sensor Speed -25 to 25.2 VDC Wire Leads -40 °C to 85 °C	Each	1+ HK$305.370 5+ HK$267.200 10+ HK$221.390	Min: 1 / Mult: 1	-	4.75VDC	-	25.2VDC	-	Wire Leads	-	-40°C	-	85°C	-	-	-	-	-	-	-	-	-	-	-	-
1GT101DC	1225630 Data Sheet RoHS	HONEYWELL Hall Effect Sensor Geartooth GT Series Sink Output Flange Mount 4.5 to 26.5 Vdc	Each	1+ HK$1,141.130 5+ HK$1,103.730 10+ HK$1,081.660 25+ HK$1,059.590 50+ HK$1,037.510 More Pricing...	Min: 1 / Mult: 1	-	4.5VDC	-	24VDC	-	Cable	-	-40°C	-	150°C	-	Hall Effect Gear Tooth	-	-	-	-	-	-	-	17.86mm	-	1GT Series
3040A	4659341 Data Sheet RoHS	HONEYWELL Speed Sensor Industrial VRS Magnetic/General Purpose 0.38 m/s Power Output Series	Each	1+ HK$2,628.990 5+ HK$2,542.790 10+ HK$2,491.940 25+ HK$2,441.080	Min: 1 / Mult: 1	-	-	-	-	-	Connector	-	-55°C	-	120°C	-	VRS General Purpose	-	-	70V p-p	85mH	12DP (Module 2.11) or Coarser	120ohm	162ohm	19.05mm	0.38m/s	Power Output Series
SNDH-T4C-G01	4668439 Data Sheet RoHS	HONEYWELL Hall Effect Sensor Connector 4.5 to 18 Vdc -40 °C to 150 °C SNDH-T Series	Each	1+ HK$1,290.740	Min: 1 / Mult: 1	-	4.5VDC	-	18VDC	-	Connector	-	-40°C	-	150°C	-	-	-	-	-	-	-	-	-	15mm	-	SNDH-T Series
SNG-QPDB-002	2773614 Data Sheet RoHS	HONEYWELL Sensor Speed and Direction Quadrature SNG-Q Series Connector with Cable Straight Exit	Each	1+ HK$1,020.650 5+ HK$962.430 10+ HK$944.990 25+ HK$926.100	Min: 1 / Mult: 1	-	4.5VDC	-	26VDC	-	Cable with Connector	-	-40°C	-	150°C	-	-	-	-	-	-	-	-	1kohm	14.95mm	-	SNG-Q Series
