Microswitch Snap Action Switches

IMPORTANT NOTICE:

We are currently experiencing higher than normal order volumes at our Singapore warehouse. While all orders are being processed, some shipments may be delayed by 1–2 business days. Thank you for your patience and continued support.

Element14 provides microswitches, also known as snap-action switches, that are designed to operate in applications requiring fast and reliable switching with minimal actuation force. These switches feature a mechanism that instantly changes contacts when the actuator is triggered, providing a quick response.

Microswitches are widely used in safety circuits and applications where precision and speed are critical. Their high reliability and ability to handle both low and high currents make them ideal for demanding industrial, automotive, and consumer applications.

Applications:

Safety Systems: Door switches and safety interlocks in industrial machinery.
Appliances: Limit switches in washing machines, ovens, and dishwashers.
Automotive: Seatbelt and airbag activation systems.

Manufacturer Part No	Order Code	Manufacturer / Description	Price For	Price	Microswitch Type	Limit Switch Actuator	Microswitch Actuator	Contact Configuration	Contact Current AC Max	Switch Terminals	Switch Operation	Contact Voltage AC Max	Contact Current Max	Actuator / Cap Colour	Contact Voltage DC Nom	Contact Current DC Max	Product Range	Contact Voltage DC Max	Contact Voltage AC Nom	Operating Force Max

DB3C-A1AA	1518966 Data Sheet RoHS	ZF Microswitch Subminiature Plunger SPDT Solder 100 mA	Each	1+HK$17.430 10+HK$17.340 25+HK$17.250 50+HK$17.150 100+HK$16.810	Subminiature	-	Plunger	SPDT	-	Solder	-	-	100mA	-	-	-	DB Series	-	250V	150gf
V-156-1C5	9901639 Data Sheet RoHS	OMRON Microswitch Snap Action Roller Lever SPDT Quick Connect 15 A 250 V	Each	1+HK$30.880 10+HK$30.510 25+HK$30.140 50+HK$26.350 100+HK$25.680 More Pricing...	Snap Action	-	Roller Lever	SPDT	-	Quick Connect	-	-	15A	-	250V	-	V Series	-	250V	125gf
DB2C-A1RC	1519000 Data Sheet RoHS	ZF Microswitch Subminiature Roller Lever SPDT Solder 10.1 A	Each	1+HK$30.100 10+HK$26.850 25+HK$23.600 50+HK$20.350 100+HK$19.950	Subminiature	-	Roller Lever	SPDT	-	Solder	-	-	10.1A	-	-	-	DB Series	-	250V	95gf
DB1C-A1RC	8786453 Data Sheet RoHS	ZF Microswitch Subminiature Roller Lever SPDT Solder 6 A 12 VDC	Each	1+HK$27.260 10+HK$25.670 25+HK$25.590 50+HK$23.620 100+HK$21.640	Subminiature	-	Roller Lever	SPDT	-	Solder	-	-	6A	-	12VDC	-	DB Series	-	250V	55gf
DC3C-L1RC	1519021 Data Sheet RoHS	ZF Microswitch Snap Action Roller Lever SPDT Quick Connect Solder 100 mA 30 V	Each	1+HK$27.850 5+HK$27.780 10+HK$27.710 20+HK$26.590 50+HK$24.530	Snap Action	-	Roller Lever	SPDT	-	Quick Connect, Solder	-	-	100mA	-	30V	-	DC Series	-	250V	200N
BZ-2RQ1-A2	1608177 Data Sheet RoHS	HONEYWELL Microswitch Standard Overtravel Plunger SPDT Screw 15 A 250 V	Each	1+HK$172.350 5+HK$166.600 10+HK$160.850 20+HK$155.100 50+HK$152.360	-	-	-	-	-	-	-	-	15A	-	250V	-	BZ Series	-	277V	3.61N
11SM1-T	1796384 Data Sheet RoHS	HONEYWELL Microswitch Subminiature Pin Plunger SPDT Solder 5 A 30 VDC	Each	1+HK$103.060 5+HK$95.520 10+HK$87.980 20+HK$85.890 50+HK$85.370	Subminiature	-	Pin Plunger	SPDT	-	Solder	-	-	5A	-	30V	-	SM Series	-	250V	0
DC2C-A1RB	2074291 Data Sheet RoHS	ZF MICRO SW ROLLER LEVER SPDT 10.1A 250V	Each	1+HK$36.790	-	-	-	-	-	-	-	-	-	-	-	-	-	-	250V	-
11-104	2292947 Data Sheet RoHS	ITW SWITCHES Microswitch Miniature Pin Plunger SPDT Solder 10 A 28 VDC	Each	1+HK$262.720 5+HK$240.710 10+HK$218.690 20+HK$201.080 50+HK$187.140	-	-	-	-	-	-	-	-	10A	-	28VDC	-	11 Series	-	250V	8ozf
D2MQ-4L-1	9901914 Data Sheet RoHS	OMRON Microswitch Snap Action Lever SPDT Solder 500 mA 30 VDC	Each	1+HK$13.210 10+HK$13.130 25+HK$13.060 50+HK$12.970 100+HK$12.720	Snap Action	-	Lever	SPDT	-	Solder	-	-	500mA	-	30V	-	D2MQ Series	-	-	0.39N
V7-6C17D8-000-2.	2526079 Data Sheet RoHS	HONEYWELL Microswitch Type:Miniature	Each	1+HK$36.600 5+HK$35.280 10+HK$33.950 20+HK$28.700	Miniature	-	Straight Lever	SPDT	-	Quick Connect	-	-	15A	-	-	-	V7 Series	-	125V	14ozf
ABV1214513	3928684 Data Sheet RoHS	PANASONIC Microswitch Miniature Simulated Roller Lever SPDT Quick Connect 3 A	Each	1+HK$27.220	Miniature	-	Simulated Roller Lever	SPDT	-	Quick Connect	-	-	3A	-	-	-	ABV Series	-	250V	1.96N
V4NCT7	1162606 Data Sheet RoHS	SAIA-BURGESS Microswitch Subminiature IP40 Snap Action Plunger SPDT Solder 5 A 30 VDC	Each	1+HK$18.310 10+HK$15.400 25+HK$14.890 50+HK$14.540 100+HK$14.280	Snap Action	-	Plunger	SPDT	-	Solder	-	-	5A	-	30V	-	V4N Series	-	250V	1.7N
SS-5GL	103444 Data Sheet RoHS	OMRON ELECTRONIC COMPONENTS Microswitch Subminiature Snap Action Hinge Lever SPDT Solder 5 A	Each	1+HK$16.210 10+HK$15.330 25+HK$14.850 50+HK$14.310 100+HK$13.010	Snap Action	-	Hinge Lever	SPDT	-	Solder	-	-	5A	-	-	-	SS Series	-	125V	0.49N
D2F-01L	9901957 Data Sheet RoHS	OMRON ELECTRONIC COMPONENTS Microswitch Snap Action Lever SPDT Through Hole 100 mA 30 V	Each	1+HK$12.080 10+HK$11.550 25+HK$11.020 50+HK$10.490 100+HK$9.960	Snap Action	-	Lever	SPDT	-	Through Hole	-	-	100mA	-	30V	-	D2F Series	-	-	0.78N
V4LS	1162617 Data Sheet RoHS	SAIA-BURGESS Microswitch Subminiature Snap Action Plunger SPDT Wire Leaded 5 A 250 V	Each	1+HK$83.190 5+HK$82.560 10+HK$81.920 20+HK$81.760 50+HK$81.590	Snap Action	-	Plunger	SPDT	-	Wire Leaded	-	-	5A	-	250V	-	V4L Series	-	250V	2.5N
D2FL	9901671 Data Sheet RoHS	OMRON ELECTRONIC COMPONENTS Microswitch Snap Action Lever SPDT Solder 3 A 30 V	Each	1+HK$11.840 10+HK$10.520 25+HK$10.310 50+HK$9.090 100+HK$8.970 More Pricing...	Snap Action	-	Lever	SPDT	-	Solder	-	-	3A	-	30V	-	D2F Series	-	125V	80gf
SS-5GL2	103445 Data Sheet RoHS	OMRON ELECTRONIC COMPONENTS Microswitch Snap Action Hinge Roller Lever SPDT Solder Lug 5 A	Each	1+HK$21.180 10+HK$17.540 25+HK$16.270 50+HK$15.370 100+HK$14.520	Snap Action	-	Hinge Roller Lever	SPDT	-	Solder Lug	-	-	5A	-	-	-	-	-	125V	0.49N
DB2C-C1AA	1519007 Data Sheet RoHS	ZF Microswitch Subminiature Plunger SPDT Through Hole 10.1 A	Each	1+HK$16.870 10+HK$14.550 25+HK$13.500 50+HK$12.750 100+HK$12.050	Subminiature	-	Plunger	SPDT	-	Through Hole	-	-	10.1A	-	-	-	DB Series	-	250V	2.5N
1117.0106-01	1839434 Data Sheet RoHS	MARQUARDT Microswitch Snap Action Plunger SPST-NO Quick Connect Solder 16 A	Each	1+HK$77.930 5+HK$77.640 10+HK$77.350 20+HK$77.050 50+HK$74.330	Snap Action	-	Plunger	SPST-NO	-	Quick Connect, Solder	-	-	16A	-	-	-	1117 Series	-	400V	3.5N
Z-15GW22B	1181283 Data Sheet RoHS	OMRON INDUSTRIAL AUTOMATION Microswitch Snap Action Roller Lever SPDT Screw 15 A 250 VDC	Each	1+HK$116.660 5+HK$95.960 10+HK$94.050 20+HK$92.130 50+HK$90.210	Snap Action	-	Roller Lever	SPDT	-	Screw	-	-	15A	-	250V	-	Z Series	-	240VAC	160gf
XCG3-S1Z1	7771630 Data Sheet RoHS	SAIA-BURGESS Microswitch Snap Action Roller Lever SPST Solder 5 A	Each	1+HK$26.480 10+HK$26.350 25+HK$26.220 50+HK$26.090 100+HK$22.300	-	-	-	-	-	-	-	-	-	-	-	-	XC Series	-	250V	-
D2F01L3D	1961082 Data Sheet RoHS	OMRON ELECTRONIC COMPONENTS Microswitch Miniature Simulated Roller Lever SPDT Solder 100 mA 30 VDC	Each	1+HK$28.910 10+HK$22.250 25+HK$21.390 50+HK$20.520 100+HK$19.930	Miniature	-	-	SPDT	-	Solder	-	-	100mA	-	30V	-	D2F Series	-	-	1.47N
V-166-1A5 BY OMI	3460650 Data Sheet RoHS	OMRON ELECTRONIC COMPONENTS Microswitch Miniature Hinge Roller Lever SPDT Solder Lug 16 A	Each	1+HK$21.960 10+HK$20.340 25+HK$19.560 50+HK$18.970 100+HK$18.190	Miniature	-	Hinge Roller Lever	SPDT	-	Solder Lug	-	-	16A	-	-	-	V Series	-	250V	1.23N
DM1-01P-30-3	1735364 Data Sheet RoHS	MULTICOMP PRO Microswitch Subminiature Short Lever SPDT PC Pin 1 A	Each	1+HK$4.240 25+HK$3.660 100+HK$3.460 250+HK$2.490 1500+HK$2.310 More Pricing...	Subminiature	-	Short Lever	SPDT	-	PC Pin	-	-	1A	-	-	-	Multicomp Pro Microswitches	-	125V	30gf
